Description

AIR-CAP3702I-E-K9 is one of the 3700 series AP, needing wireless controller, providing internal antenna and E regulatory domain. Based on the Cisco Aironet heritage of RF excellence, the 3700 Series utilizes a Purpose-built innovative chipset to provide a high density experience for enterprise network. 4 x 4 MIMO (multiple-input multiple-output) technology with three-spatial-stream offers a greater coverage for more reliability and capacity than competing access points. Modular architecture enables flexible add-on options, which include Wireless Security Module, Cisco Universal Small Cell 5310 Module and Cisco Aironet 802.11ac Wave 2 Module.

Specifications

• Product Code: AIR-CAP3702I-E-K9
• WiFi Standards: 802.11a/b/g/n/ac
• Ideal For: Midsize or large enterprises that require mission-critical traffic
• Max Data Rate 5GHz: 1.3 Gbps
• MIMO Radio Design: Spatial Streams: 4 x 4:3
• Client count/ClientLink client count: 200/128
• Controller Available: Yes
• Power
  • 4 x 4:3 operation:
  • 802.3at PoE+
  • Enhanced PoE, Universal PoE (UPOE)
  • 3 x 3:3 operation: 802.3af PoE
• Antenna: Internal Antenna
• Regulatory Domain
  • E (E regulatory domain):
  • 2.412 to 2.472 GHz; 13 channels
  • 5.180 to 5.320 GHz; 8 channels
  • 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz)
• Dimensions (W x L x H): 22.1 x 22.1 x 5.4 cm (without mounting bracket)
• Package Weight: 1.72 Kg

For more information of this Cisco AIR-CAP3702I-E-K9, please visit Cisco website:

https://www.cisco.com/c/en/us/td/docs/wireless/access_point/3700/quick/guide/ap3700getstart.html
